ReAct Agent

Overview

ReAct Agent is a general paradigm that combines reasoning and action capabilities to solve complex tasks. Leveraging this paradigm, the user only needs to specify the goal with prompt and provide available tools, and the LLM will decide how to achieve the goal and take actions autonomously.

This quickstart introduces a small example that demonstrate how to build a streaming ReAct Agent with Flink Agents:

The Review Analysis agent processes a stream of product reviews and uses a single agent to extract a rating (1–5) and unsatisfied reasons from each review. And notify the shipping manager if a review includes dissatisfaction with the shipping process.

Code Walkthrough

Prepare Agents Execution Environment

Create the agents execution environment, and register the available chat model connections and tools to the environment.

Python

# Set up the Flink streaming environment and the Agents execution environment.
env = StreamExecutionEnvironment.get_execution_environment()
agents_env = AgentsExecutionEnvironment.get_execution_environment(env)

# Add Ollama chat model connection and notify shipping manager tool to be used
# by the Agent.
agents_env.add_resource(
  "ollama_server",
  ResourceType.CHAT_MODEL_CONNECTION,
  ResourceDescriptor(clazz=ResourceName.ChatModel.OLLAMA_CONNECTION, request_timeout=120),
).add_resource(
  "notify_shipping_manager", ResourceType.TOOL, Tool.from_callable(notify_shipping_manager)
)

Java

// Set up the Flink streaming environment and the Agents execution environment.
StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
AgentsExecutionEnvironment agentsEnv =
        AgentsExecutionEnvironment.getExecutionEnvironment(env);

// Add Ollama chat model connection and record shipping question tool to be used
// by the Agent.
agentsEnv
        .addResource(
                "ollamaChatModelConnection",
                ResourceType.CHAT_MODEL_CONNECTION,
                CustomTypesAndResources.OLLAMA_SERVER_DESCRIPTOR)
        .addResource(
                "notifyShippingManager",
                ResourceType.TOOL,
                org.apache.flink.agents.api.tools.Tool.fromMethod(
                        ReActAgentExample.class.getMethod(
                                "notifyShippingManager", String.class, String.class)));

Create the ReAct Agent

Create the ReAct Agent instance, configure the chat model, prompt and the output schema of result to be used.

Python

review_analysis_react_agent = ReActAgent(
  chat_model=ResourceDescriptor(
      clazz=ResourceName.ChatModel.OLLAMA_SETUP,
      connection="ollama_server",
      model="qwen3:8b",
      tools=["notify_shipping_manager"],
  ),
  prompt=review_analysis_react_prompt,
  output_schema=ProductReviewAnalysisRes,
)

Java

// Create ReAct agent.
ReActAgent reviewAnalysisReactAgent = getReActAgent();

 private static ReActAgent getReActAgent() {
     return new ReActAgent(
             ResourceDescriptor.Builder.newBuilder(ResourceName.ChatModel.OLLAMA_SETUP)
                     .addInitialArgument("connection", "ollamaChatModelConnection")
                     .addInitialArgument("model", "qwen3:8b")
                     .addInitialArgument(
                             "tools", Collections.singletonList("notifyShippingManager"))
                     .build(),
             reviewAnalysisReactPrompt(),
             CustomTypesAndResources.ProductReviewAnalysisRes.class);
 }

Integrate the ReAct Agent with Flink

Produce a source DataStream by reading a product review text file, and use the ReAct Agent to analyze the review and generate result DataStream. Finally print the result DataStream.

Python

# Read product reviews from a text file as a streaming source.
# Each line in the file should be a JSON string representing a ProductReview.
product_review_stream = env.from_source(
    # Target the single file, not the resources/ dir: Flink's enumerator
    # recurses, so files like skills/SKILL.md would be parsed as reviews.
    source=FileSource.for_record_stream_format(
        StreamFormat.text_line_format(),
        f"file:///{current_dir}/resources/product_review.txt",
    )
    .monitor_continuously(Duration.of_minutes(1))
    .build(),
    watermark_strategy=WatermarkStrategy.no_watermarks(),
    source_name="streaming_agent_example",
).map(
    lambda x: ProductReview.model_validate_json(
        x
    )  # Deserialize JSON to ProductReview.
)

# Use the ReAct agent to analyze each product review and notify the shipping manager
# when needed.
review_analysis_res_stream = (
    agents_env.from_datastream(
        input=product_review_stream, key_selector=lambda x: x.id
    )
    .apply(review_analysis_react_agent)
    .to_datastream()
)

# Print the analysis results to stdout.
review_analysis_res_stream.print()

# Execute the Flink pipeline with the Flink job name.
agents_env.execute("ReAct Agent Example Job")

Java

// Read product reviews from input_data.txt file as a streaming source.
// Each element represents a ProductReview.
DataStream<Row> productReviewStream =
        env.fromSource(
                FileSource.forRecordStreamFormat(
                                new TextLineInputFormat(),
                                new Path(inputDataFile.getAbsolutePath()))
                                .monitorContinuously(Duration.ofMinutes(1))
                                .build(),
                        WatermarkStrategy.noWatermarks(),
                        "react-agent-example")
                .map(
                        inputStr -> {
                            Row row = Row.withNames();
                            CustomTypesAndResources.ProductReview productReview =
                                    MAPPER.readValue(
                                            inputStr,
                                            CustomTypesAndResources.ProductReview.class);
                            row.setField("id", productReview.getId());
                            row.setField("review", productReview.getReview());
                            return row;
                        });

// Use the ReAct agent to analyze each product review and
// record shipping question.
DataStream<Object> reviewAnalysisResStream =
        agentsEnv
                .fromDataStream(productReviewStream)
                .apply(reviewAnalysisReactAgent)
                .toDataStream();

// Print the analysis results to stdout.
reviewAnalysisResStream.print();

// Execute the Flink pipeline with the Flink job name.
agentsEnv.execute("ReAct Agent Example Job");

See Integrate with Flink for details on integrating agents with the Flink DataStream and Table API.

Run the Example

Prerequisites

Unix-like environment (we use Linux, Mac OS X, Cygwin, WSL)
Git
Java 11+
Python 3.10, 3.11 or 3.12

Preparation

Prepare Flink and Flink Agents

Follow the installation instructions to setup Flink and the Flink Agents.

Clone the Flink Agents Repository (if not done already)

git clone https://github.com/apache/flink-agents.git
cd flink-agents

For python examples, you can skip this step and submit the python file in installed flink-agents wheel.

Deploy a Standalone Flink Cluster

You can deploy a standalone Flink cluster in your local environment with the following command.

Python

export PYTHONPATH=$(python -c 'import sysconfig; print(sysconfig.get_paths()["purelib"])')
$FLINK_HOME/bin/start-cluster.sh

Java

Build Flink Agents from source to generate example jar. See installation for more details.
Start the Flink cluster
```
$FLINK_HOME/bin/start-cluster.sh
```

To run example on JDK 21+, append jvm option --add-exports=java.base/jdk.internal.vm=ALL-UNNAMED to env.java.opts.all in $FLINK_HOME/conf/config.yaml before start the flink cluster.

You can refer to the local cluster instructions for more detailed step.

If you can’t navigate to the web UI at localhost:8081, you can find the reason in $FLINK_HOME/log. If the reason is port conflict, you can change the port in $FLINK_HOME/conf/config.yaml.

Prepare Ollama

Download and install Ollama from the official website.

Ollama server 0.9.0 or higher is required.

Then pull the qwen3:8b model, which is required by the quickstart examples

ollama pull qwen3:8b

Submit Flink Agents Job to Standalone Flink Cluster

Submit to Flink Cluster

Python

export PYTHONPATH=$(python -c 'import sysconfig; print(sysconfig.get_paths()["purelib"])')

# Run review analysis example
$FLINK_HOME/bin/flink run -py ./flink-agents/python/flink_agents/examples/quickstart/react_agent_example.py
# or submit the example python file in installed flink-agents wheel
$FLINK_HOME/bin/flink run -py  $PYTHONPATH/flink_agents/examples/quickstart/react_agent_example.py

Java

$FLINK_HOME/bin/flink run -c org.apache.flink.agents.examples.ReActAgentExample ./flink-agents/examples/target/flink-agents-examples-$VERSION.jar

Now you should see a Flink job submitted to the Flink Cluster in Flink web UI localhost:8081

After a few minutes, you can check for the output in the TaskManager output log.
